TotalSaver by Totaline T257-3728 1/4 HP 208/230V PSC Outdoor Condenser Fan Motor 1075 RPM

Condition: New, unused outdoor condenser fan motor in box; box shows visible storage wear, tape, scuffs, tears, punctures, and dents. Capacitor is not included, as stated on the packaging. The TotalSaver by Totaline T257-3728 is a single-phase PSC outdoor condenser fan motor designed for HVAC systems, especially outdoor air conditioner and heat pump condenser units. This motor is rated 1/4 HP, operates on 208/230V, runs at 1075 RPM, and features reversible rotation. It drives the condenser fan blade to move air across the condenser coil, helping the system reject heat and maintain proper cooling performance. Features Brand / Series: TotalSaver by Totaline Model: T257-3728 Product Type: Outdoor condenser fan motor Application: Outdoor condenser fan motor Horsepower: 1/4 HP Voltage: 208/230V Phase: 1 phase Frequency: 60 Hz Speed: 1075 RPM Number of Speeds: 1 Amperage: 1.8 A Motor Type: PSC — permanent split capacitor Capacitor Required: 5 µF / 370V, not included Protection: Thermal protector Insulation Class: Class B Ambient Temperature Rating: 60°C Rotation: Reversible Motor Shaft Rotation: CWSE/CCWLE or CCWSE/CWLE, depending on wiring Frame: 48 Enclosure: TE — totally enclosed Mounting: Base, stud, strap Shaft: 6.5″ x 1/2″ Bearings: Sleeve bearings Country of Manufacture: China Date on Label: 2015.04.28 Barcode / UPC: 00822529332352 Applications The T257-3728 is used in outdoor condenser fan assemblies where a reliable single-speed motor is needed to rotate the fan blade. Typical applications include: Residential central air conditioner outdoor units Heat pump condenser sections Residential HVAC systems Light commercial condenser units Service replacement for failed condenser fan motors Air conditioning repair and maintenance HVAC contractor replacement inventory This motor can be part of a larger condenser assembly that includes the fan blade, run capacitor, contactor, compressor, condenser coil, protective grille, wiring, and outdoor cabinet. Before installation, confirm compatibility by horsepower, voltage, speed, shaft diameter, shaft length, mounting type, rotation direction, and capacitor rating. Motor Specifications Horsepower: 1/4 HP Voltage: 208/230V RPM: 1075 RPM No. of Speeds: 1 Frame: 48 Phase: Single phase Motor Type / Design: PSC Enclosure Type: TE Insulation Class: B Thermal Protection: Thermal protector Ambient Rating: 60°C Mounting: Base, stud, strap Shaft Size: 6.5″ x 1/2″ Bearings: Sleeve Capacitor Required: 5 µF / 370V, not included Motor Shaft Rotation: CWSE/CCWLE or CCWSE/CWLE, depending on wiring CFM: Not specified; actual airflow depends on the fan blade, blade diameter, blade pitch, shroud, grille, and condenser unit design Cross-Referenced Models The packaging lists the following cross-reference models: A.O. Smith FSE1026S Emerson 1860 GE 3728 Gemline EM3728 Marathon X213 Smart SE3728 Source 1 S1-FHM3728 Wagner WG3728 Comparable Products A.O. Smith FSE1026S — comparable 1/4 HP condenser fan motor Emerson 1860 — HVAC condenser fan motor replacement equivalent GE 3728 — cross-reference replacement model for 208/230V applications Gemline EM3728 — compatible PSC condenser fan motor Marathon X213 — comparable motor for outdoor condenser units Smart SE3728 — similar replacement model Source 1 S1-FHM3728 — replacement condenser fan motor Wagner WG3728 — comparable replacement condenser fan motor Installation Notes Installation should be performed by a qualified HVAC technician. Before mounting, compare the original motor specifications with this unit: 1/4 HP, 208/230V, 1075 RPM, Frame 48, 1/2″ shaft, shaft length, mounting style, reversible rotation, direction of rotation, and required 5 µF / 370V run capacitor. The capacitor is not included, so a properly rated capacitor must be purchased separately or replaced with a verified working compatible capacitor. Common Requests: TotalSaver T257-3728 outdoor condenser fan motor replacement T257-3728 1/4 HP 208/230V 1075 RPM condenser fan motor Replacement motor for GE 3728 and Wagner WG3728 PSC condenser fan motor 5 µF 370V capacitor required Source 1 S1-FHM3728 cross reference motor replacement Related TotalSaver T257-3728, Totaline T257-3728, condenser fan motor, outdoor condenser fan motor, HVAC fan motor, 1/4 HP condenser motor, 208/230V fan motor, 1075 RPM motor, PSC motor, permanent split capacitor motor, Frame 48 motor, 1/2 inch shaft motor, reversible fan motor, air conditioner outdoor unit motor, motor for AC condenser fan blade, device to rotate condenser fan blade, A.O. Smith FSE1026S, Emerson 1860, GE 3728, Gemline EM3728, Marathon X213, Smart SE3728, Source 1 S1-FHM3728, Wagner WG3728. P128
